Seat ventilation

Car seat ventilation refers to the ventilation function that can be achieved by designers using a fan to inject air into the seat, in which the air flows out from the small holes on the seat surface. This effectively improves the air circulation environment on the contact surface between the human body and the seat surface. The contact surface will be dry and comfortable even after sitting for a long time.

Based on MindMotion’s MM32SPIN023C microcontroller, the seat ventilation takes MM32SPIN023C as its main control.



Seat ventilation


MM32 MCU Model:

MM32SPIN023C Series

MCU Specifications:

- Memory and computing resources: 32KB Flash, 4KB SRAM and maximum main frequency 60MHz
- 7 timer resources: one 16-bit advanced timer, one 32-bit general-purpose timer, three basic timers, one 12-bit IWDG and one 24-bit Systick
- Support 2-channel DMA
- Hardware Divider HW-Div
- One 12-bit analog-to-digital converter ADC, 9 channels supported and sampling rate 1Msps
- Designed for motor applications with built-in 2 comparators, 2 rail-to-rail operational amplifiers, and 6 integrated MOSFETs; capable of sustaining a continuous driving current of up to 2A
- Support UART/SPI communication
- Support 6.5-18V power supply
- Operating ambient temperature -40℃~105℃
- Provide QFN32 package type

Features:

- Highly integrated solution with LDO, PreDriver and MOSFET
- All in one
- Overvoltage and overcurrent protection
- Position speed control
- Single UART communication
