MM32G0160

  • Overview
  • Document
  • Tools & Software
  • Target Application
  • Selection
  • Product Information

Product Description

This device is a 32-bit microcontroller based on the high-performance Arm® Cortex-M0 core, operating at a frequency of up to 96MHz, with built-in high-speed memory, an extensive range of enhanced I/O ports and peripherals.

- 128KB Flash and 16KB SRAM

- One 12-bit ADC and two analog comparators

- One 16-bit advanced timer, one 32-bit general-purpose timer, one 16-bit general-purpose timer, three 16-bit basic timers and one 16-bit low-power timer

- Five UART interfaces, two SPI interfaces, one I2C interface and one I3C slave interface

- One USB interface

- One FlexCAN-FD interface

- Working voltage: 2.0V~5.5V

- Working temperature range (ambient temperature): -40℃ to 105℃ extendable industrial grade (V is the suffix)

- Provide three package types: LQFP48, LQFP32 and QFN28


It is suitable for a wide range of applications:

- Industrial control

- Digital power

- New energy photovoltaic

- Motor control

- Computer accessory

- Smart lock



Product Features

Related Videos

    No Details

Leaflet

  • MM32G01xx Leaflet (Chinese)
    Chinese 1.0 PDF 2.91MB 2023.02.14

    Description： Introduct the main features, functions, advantages, ordering information and development tools support of related products or series.

  • MM32G01xx Leaflet (English)
    English 1.0 PDF 2.83MB 2023.02.14

    Description： Introduct the main features, functions, advantages, ordering information and development tools support of related products or series.

Data Sheet

  • MM32G0160 Datasheet (Chinese)
    Chinese 0.6 PDF 2.34MB 2023.05.09

    Description： Supports MM32G0160 series, provide detailed specifications, pin definition, electrical characteristics and packaging information.

  • MM32G0160 Datasheet (English)
    English 0.6 PDF 2.12MB 2023.05.09

    Description： Supports MM32G0160 series, provide detailed specifications, pin definition, electrical characteristics and packaging information.

User Manual

  • MM32G0160 User Manual (Chinese)
    Chinese 0.5 PDF 18.78MB 2023.04.17

    Description： Supports MM32G0160 series, providing a complete system architecture, memory and all peripheral details and register descriptions.

  • MM32G0160 User Manual (English)
    English 0.5 PDF 15.83MB 2023.04.17

    Description： Supports MM32G0160 series, providing a complete system architecture, memory and all peripheral details and register descriptions.

Errata Sheet

  • MM32G0160 Errata Sheet (Chinese)
    Chinese 0.9 PDF 224.07KB 2023.04.04

    Description： Supports the MM32G0160 series, list the known issues and provide recommended solutions.

  • MM32G0160 Errata Sheet (English)
    English 0.9 PDF 140.86KB 2023.04.04

    Description： Supports the MM32G0160 series, list the known issues and provide recommended solutions.

Application Note

Lib Samples

Recommended Tools

  • MM32-LINK MINI Emulator

    Support MM32 MCU SWD programming and debugging, compatible with CMSIS-DAP debugging channel

    Support CDC virtual serial port, baud rate support 9600 / 14400 / 19200 / 28800 / 38400 / 56000 / 57600 / 115200 etc

    Support firmware update and function configuration via U-Disk

    Driver-free installation, supports Windows and Linux operating systems

  • MiniBoard (MM32G0163D6PV)

    On-board main control: MM32G0163D6PV
    - 32bit Arm Cortex-M0
    - 128KB Flash, 16KB SRAM
    - LQFP48

    On-board resources:
    - 4 user LEDs
    - 3 user press keys and 1 reset key
    - 3 adjustable potentiometers
    - PWM buzzer
    - 16M SPI FLASH
    - 2K EEPROM

    On-board interface:
    - 2 x USB Type-C(MCU USB and USB-UART CH340)
    - CAN connector (On-board transceiver chip)
    - I3C connector
    - 20PIN SWD adjustable interface
    - Arduino UNO compatible expansion connector
    - MM32G0163D6PV full-pin expansion connector

    Power supply:
    - USB TYPE-C

Recommended Software

  • IAR Pack

    When using IAR integrated development environment to develop MM32 microcontroller, you need to install this support package, so that you can select MM32 chip model, debug and download in IAR.

  • KEIL Pack

    When using KEIL integrated development environment to develop MM32 microcontroller, you need to install this support package, so that you can select MM32 chip model, debug and download in KEIL.

  • J-Link Pack

    When using J-Link debuggerto debug MM32 microcontroller or using J-Flash to make programming, this supportpackage needs to be installed to realize the selection of MM32 device in J-Flash; When J-Li...
See More

Target Application

    No Details

Selection

Buy

Part No.

Core

Max Speed (MHz)

Flash (KB)

RAM (KB)

I/O#

Advanced TMR

GP TMR

UART

LPUART

I²C

SPI

USB 2.0 FS

CAN 2.0B

Ethernet

ADC (1Msps, 12bit)

ADC (3Msps, 12bit)

DAC (12bit)

ACMP

OpAmp

Pin Counts

Package

Package Size

Operation Temp

样片申请
Agent Channel Link
MM32G0163D3NV
M0
96
128
16
24
1
5
4
1
1
1
D
1 (FD)
-
13ch
-
-
2
-
28
QFN
4x4
-40~105C
样片申请
Agent Channel Link
MM32G0163D4QV
M0
96
128
16
27
1
5
4
1
1
2
D
1 (FD)
-
13ch
-
-
2
-
32
QFN
5x5
-40~105C
样片申请
Agent Channel Link
MM32G0163D4PV
M0
96
128
16
27
1
5
4
1
1
2
D
1 (FD)
-
13ch
-
-
2
-
32
LQFP
7x7
-40~105C
样片申请
Agent Channel Link
MM32G0163D6PV
M0
96
128
16
40
1
5
4
1
1
2
D
1 (FD)
-
13ch
-
-
2
-
48
LQFP
7x7
-40~105C

Sample Application

Customer Related Information

Sample Related Information
Project Related Information

Agent Related Information

We offer the following online ordering options

MM32F0010

Home > 产品 > MM32F > MM32F Value Line > MM32F0010

Dealer
Stock*
Unit Price
Quantity
1548
$5.25
50
Standard global delivery $4.99
Add To Cart
  • Americas (inventory)
  • EMEA（inventory）
  • Asia（inventory）
  • Japan（inventory）
Dealer
Stock*
1548
Order Now
1548
Order Now
1548
Order Now
1548
Order Now
* The price may change at any time

Product Information

Part No.

Packing

Package Type Package Drawing

MOQ
REACH Declaration
ROHS Declaration
ROHS Report
MSL
Peak Package Body Temperature
MM32G0163D3NV
3
260℃
MM32G0163D4QV
3
260℃
MM32G0163D4PV
Tray
2500
3
260℃
MM32G0163D6PV
Tray
2500
3
260℃
