Product Description

Arm v8-M architecture (compatible with Cortex-M33), with a clock speed of up to 200MHz. It features a Floating Point Unit (FPU), Digital Signal Processing (DSP) unit, MindSwitch interconnection matrix, CORDIC trigonometric function accelerator, and integrates a wide range of peripheral modules and ample I/O ports.

- Up to 2MB Flash, 256KB RAM + 4KB Retention RAM

- Multiple communication interfaces: 8x USART/LPUART, 3x SPI, 2x I2C

- 1x Ethernet 10/100Mbps MII/RMII interface

- 1x High-Speed USB, 1x Full-Speed USB

- 2x FlexCAN modules supporting CAN 2.0B and CAN-FD, up to 8Mbps

- Camera interface DCI, up to 14-bit wide, supporting Bayer/YCbCr/RGB/JPEG formats

- 16-bit parallel FMC, supporting SDRAM and 8080 displays

- Hardware AES-128, SHA-256, TRNG, supporting AES-based online decryption

- 2x Advanced Timers, 3x 3MSPS 12b ADC

- Operating voltage range of 2.7-3.6V, with 5V-tolerant I/O

- Operating temperature range of -40℃ to 105℃

- Available in LQFP64, LQFP100, and LQFP144 packages


Applications:

- Industrial automation

- Elevator control

- Fire control

- Energy storage control

- Power electronics control

- Smart home appliance control

- Smart home control

- Intelligent cockpit coprocessor

- Industrial HMI



Product Features

Related Videos

    No Details

Leaflet

Data Sheet

  • MM32H5420 Datasheet (Chinese)
    Chinese 0.5 PDF 3.42MB 2024.08.27

    Description: Supports MM32H5420 series, provide detailed specifications, pin definition, electrical characteristics and packaging information.

User Manual

  • MM32H5420 User Manual (Chinese)
    Chinese 0.51 PDF 75.19MB 2024.11.04

    Description: Supports MM32H5420 series, providing a complete system architecture, memory and all peripheral details and register descriptions.

  • MM32H5420 User Manual (English)
    English 0.51 PDF 59.68MB 2024.11.04

    Description: Supports MM32H5420 series, providing a complete system architecture, memory and all peripheral details and register descriptions.

Lib Samples

  • MM32H5420 Lib Samples
    English 0.5.1 ZIP 4.68MB 2024.08.27

    Description: Supports MM32H5420 and the Cortex-M Microcontroller Software Interface Standard (CMSIS), MM32 Standard Peripheral Library, IAR and MDK development, and offer rich reference samples for library function and register operations.

Recommended Tools

  • MM32-LINK MINI Emulator

    Support MM32 MCU SWD programming and debugging, compatible with CMSIS-DAP debugging channel

    Support CDC virtual serial port, baud rate support 9600 / 14400 / 19200 / 28800 / 38400 / 56000 / 57600 / 115200 etc

    Support firmware update and function configuration via U-Disk

    Driver-free installation, supports Windows and Linux operating systems

Recommended Software

  • IAR Pack

    When using IAR integrated development environment to develop MM32 microcontroller, you need to install this support package, so that you can select MM32 chip model, debug and download in IAR.
  • KEIL Pack

    When using KEIL integrated development environment to develop MM32 microcontroller, you need to install this support package, so that you can select MM32 chip model, debug and download in KEIL.
  • J-Link Pack

    When using J-Link debuggerto debug MM32 microcontroller or using J-Flash to make programming, this supportpackage needs to be installed to realize the selection of MM32 device in J-Flash; When J-Li...
See More

Target Application

    No Details

Selection

Buy

Part No.

Core

Max Speed (MHz)

Flash (KB)

RAM (KB)

Backup RAM(KB)

Ext. Bus I/F

I/O#

Security

32bit DIV

Advanced TMR

GP TMR

LP TMR

WDG

RTC

U(S)ART

LPUART

I²C

I³C

SPI

I²S

USB 2.0 FS

USB 2.0 HS

CAN 2.0B

Ethernet

SDIO

QSPI

ADC (1Msps, 12bit)

ADC (3Msps, 12bit)

DAC (12bit)

ACMP

OpAmp

Segment LCD

Pin Counts

Package

Package Size

Operation Temp

样片申请
Agent Channel Link
MM32H5427G7PV
Star-MC1
200
512
256
4
FMC/SDRAM
54
AES128, SHA256, TRNG, OTFDEC
-
2
10
1
2
Y
7
1
2
-
3
3
D/H
D/H
2 (FD)
1
1
1
-
3, 18ch
2
4
-
-
64
LQFP
10x10
-40~105C
样片申请
Agent Channel Link
MM32H5427G8PV
Star-MC1
200
512
256
4
FMC/SDRAM
85
AES128, SHA256, TRNG, OTFDEC
-
2
10
1
2
Y
7
1
2
-
3
3
D/H
D/H
2 (FD)
1
1
1
-
3, 27ch
2
4
-
-
100
LQFP
14x14
-40~105C
样片申请
Agent Channel Link
MM32H5427G9PV
Star-MC1
200
512
256
4
FMC/SDRAM
117
AES128, SHA256, TRNG, OTFDEC
-
2
10
1
2
Y
7
1
2
-
3
3
D/H
D/H
2 (FD)
1
1
1
-
3, 40ch
2
4
-
-
144
LQFP
20x20
-40~105C
样片申请
Agent Channel Link
MM32H5427L7PV
Star-MC1
200
2048
256
4
FMC/SDRAM
54
AES128, SHA256, TRNG, OTFDEC
-
2
10
1
2
Y
7
1
2
-
3
3
D/H
D/H
2 (FD)
1
1
1
-
3, 18ch
2
4
-
-
64
LQFP
10x10
-40~105C
样片申请
Agent Channel Link
MM32H5427L8PV
Star-MC1
200
2048
256
4
FMC/SDRAM
85
AES128, SHA256, TRNG, OTFDEC
-
2
10
1
2
Y
7
1
2
-
3
3
D/H
D/H
2 (FD)
1
1
1
-
3, 27ch
2
4
-
-
100
LQFP
14x14
-40~105C
样片申请
Agent Channel Link
MM32H5427L9PV
Star-MC1
200
2048
256
4
FMC/SDRAM
117
AES128, SHA256, TRNG, OTFDEC
-
2
10
1
2
Y
7
1
2
-
3
3
D/H
D/H
2 (FD)
1
1
1
-
3, 40ch
2
4
-
-
144
LQFP
20x20
-40~105C
